A foundation inspection is a measured look at the concrete and the ground conditions around it, ending in a written report that sorts what you've got from what you don't. Walnut Creek Structural Engineer Pros starts with a free phone conversation about what you're seeing.
How do I know if I need a foundation inspection?
You likely need one if you can see cracks in a foundation wall or slab that are growing, doors and windows that have started to bind, or damp patches at the base of walls. Buying a house or planning to build on to one are the other common reasons. One sign alone rarely settles it.
What we're really asking is whether a crack is moving. A crack that has sat at the same width for years behaves very differently from one that has opened since you last looked, and a stain with no active moisture behind it is a different problem from a wall that reads wet. That's why we measure instead of guessing from the photo you send.
Some of what people call about turns out to be minor. If the report classifies your findings as low severity, you've paid for the answer, and that answer is worth having. If you're not sure a visit is warranted, talk it through with us on the phone first.
Closely related: load bearing wall removal plans. Want a structural engineer in Walnut Creek? Our main page lists everything.
Related reading: What Happens During Structural Engineering: The Steps Explained · How to Choose a Structural Engineer: What a Good Quote Spells Out
What happens on the visit, from start to finish?
We walk the house, record crack widths and locations, take moisture readings where they're relevant, then sort what we found by severity and tie it to probable causes. Walnut Creek Structural Engineer Pros puts all of that in a written report. Nothing gets repaired on this visit.
Crack widths are read with a crack comparator card, a printed gauge you hold against the crack, so the number in your report is one anyone can check again later. Each crack is logged with its location, so a follow-up visit compares the same crack and not a similar one. Moisture is read with a pin-type or pinless meter. A pinless meter scans the surface without marking it, while a pin-type meter probes the material directly.
A list of cracks is just a list, so the sorting is the real work. We rank each finding by severity and say what probably caused it, because the cause picks the fix. A crack from drying shrinkage and a crack from the ground shifting under a footing can look alike and call for completely different responses.
How long does the inspection take?
A bigger house with more cracks and damp spots to record means a longer visit. One crack to log is quicker than a dozen. We can't give an honest clock time until we know what you're describing, so on the call we'll set the visit time and tell you when the written report will follow.
Most of the time goes to access. Stored boxes and furniture against the walls slow down measuring. If you can pull things away from the interior and exterior walls you're worried about before we arrive, the visit goes faster.
What does it cost, and what moves the number?
A residential structural inspection and report runs $425 to $1,100. Over the phone, Walnut Creek Structural Engineer Pros can quote a usual range from your description; the exact number is set once we've walked the house. Where you land comes down to how much there is to measure and write up.
Jobs land at the high end when there are more cracks to measure and log, moisture readings across several walls, or a larger house with more foundation to cover. A single concern in one corner is a smaller write-up than a whole perimeter. A classified, written account of causes also takes more work than a verbal opinion, and that work is part of the price.
The inspection is priced separately from any repair. Any repair the report points to is quoted in writing as its own document, apart from the inspection. Repair pricing depends on what the findings call for, and we won't put a figure on it before we've measured.
Does Walnut Creek's ground and weather change what the inspection finds?
Yes, in two ways. Clear Lake-series soil here drains poorly, and its water table sits several feet down in late summer but can rise close to the surface in wet winter months. A wall that's dry in September can read differently in February, so moisture readings only mean something alongside the season they were taken in.
The second is earthquake ground movement. Much of Ygnacio Valley and the major drainages, including Tice and San Ramon Creeks, sit in mapped liquefaction zones. If your house is in one of those areas, we say so when we relate findings to causes, because it shapes what a sound repair looks like.
The large swing between day and night temperatures matters for measuring. Concrete moves a little as it warms and cools, so a single crack reading isn't the whole story. A second measurement at a different time of day tells you more than the first.
If you're planning an addition, an inspection of the existing foundation before anyone designs the new load gives you a written baseline to build from.
What do I do next?
Call Walnut Creek Structural Engineer Pros and tell us what you've noticed. A person answers and asks where the cracks are, how wide they look, whether anything is damp, and how long you've seen it. The call costs nothing, and no repair decision is needed on it.
Before we schedule anything, you'll have the typical price range. A leaking pipe or a drainage problem belongs with another trade first, and we'll say so if that's what your description sounds like.
A Few of the Specifics
In plain terms, expect steps like these:
- Walk through accessible areas and visually examine the foundation and the building for cracking, settlement, bowing, and water-related signs.
- Inspect exterior walls and interior walls, floors, and ceilings for signs associated with foundation movement.
Pricing Ranges
These ranges are a starting point for planning, and your written quote is the number that counts.
$350–$3,600
$350–$900
$600–$3,600
